| PART NO. | FERRULE CODE |
A (mm) |
B (mm) |
S (mm) |
L (mm) |
WEIGHT Kgs/1000Pcs |
L(mm) GB 6946-93 |
| SL990010 | 1 | 1.2 | 2.4 | 0.65 | 5 | 0.098 | - |
| SL990015 | 1.5 | 1.7 | 3.4 | 0.75 | 6 | 0.176 | - |
| SL990020 | 2 | 2.2 | 4.4 | 0.85 | 7 | 0.285 | - |
| SL990025 | 2.5 | 2.7 | 5.4 | 1.05 | 9 | 0.439 | - |
| SL990030 | 3 | 3.3 | 6.6 | 1.25 | 11 | 0.907 | - |
| SL990035 | 3.5 | 3.8 | 7.6 | 1.5 | 13 | 1.18 | - |
| SL990040 | 4 | 4.4 | 8.8 | 1.7 | 14 | 1.63 | - |
| SL990045 | 4.5 | 4.9 | 9.8 | 1.9 | 16 | 2.39 | - |
| SL990050 | 5 | 5.5 | 11.0 | 2.1 | 18 | 3.62 | - |
| SL990060 | 6 | 6.6 | 13.2 | 2.5 | 21 | 5.87 | 25 |
| SL990065 | 6.5 | 7.2 | 14.4 | 2.7 | 23 | 7.18 | - |
| SL990070 | 7 | 7.8 | 15.6 | 2.9 | 25 | 9.83 | 30 |
| SL990080 | 8 | 8.8 | 17.6 | 3.3 | 28 | 12.96 | 34 |
| SL990090 | 9 | 9.9 | 19.8 | 3.7 | 32 | 18.94 | 38 |
| SL990100 | 10 | 10.9 | 21.8 | 4.1 | 35 | 24.09 | 42 |
| SL990110 | 11 | 12.1 | 24.2 | 4.5 | 39 | 35.35 | 47 |
| SL990120 | 12 | 13.2 | 26.4 | 4.9 | 42 | 44.18 | 50 |
| SL990130 | 13 | 14.2 | 28.4 | 5.4 | 46 | 59.86 | 55 |
| SL990140 | 14 | 15.3 | 30.6 | 5.8 | 49 | 73.5 | 59 |
| SL990160 | 16 | 17.5 | 35.0 | 6.7 | 56 | 111 | 67 |
| SL990180 | 18 | 19.6 | 39.2 | 7.6 | 63 | 156 | 76 |
| SL990200 | 20 | 21.7 | 43.4 | 8.4 | 70 | 217 | 84 |
| SL990220 | 22 | 24.3 | 48.6 | 9.2 | 77 | 292 | 92 |
| SL990240 | 24 | 26.4 | 52.8 | 10.0 | 84 | 376 | 101 |
| SL990260 | 26 | 28.5 | 57 | 10.9 | 91 | 481 | 109 |
| SL990280 | 28 | 31.0 | 62.0 | 11.7 | 98 | 603 | 118 |
| ...... | |||||||
| ...... | |||||||
| SL990600 | 60 | 66.0 | 132.0 | 25.0 | 210 | 5880 | 248 |
