链环尺寸LINK SPECIFICATION
|
拉力负荷
PROOF LOAD |
破断负荷
BREAKING LOAD |
KG/200英尺
NET WT PER 200FT(KG) |
||||
|
链径D
DIAMETER |
内长L
INSIDE LENGTH |
外宽W
OUTSIDE WIDTH |
|||||
|
INCH
|
MM
|
MM
|
MM
|
KG
|
KG
|
B.F.(黑漆）
|
H.D.G(热镀锌）
|
|
1/8
|
3.20
|
16
|
12
|
200
|
400
|
11.4
|
11.7
|
|
5/32
|
4.00
|
18.5
|
14.5
|
300
|
600
|
18.6
|
19.0
|
|
3/16
|
4.70
|
19
|
17
|
400
|
800
|
26.2
|
27.0
|
|
7/32
|
5.50
|
20
|
19
|
550
|
1100
|
36.8
|
38.0
|
|
1/4
|
6.35
|
22
|
21
|
750
|
1500
|
50
|
51.5
|
|
5/16
|
7.94
|
26
|
26
|
1200
|
2400
|
80.0
|
82.4
|
|
3/8
|
9.50
|
28
|
32
|
1700
|
3400
|
122.0
|
125.7
|
|
7/16
|
11.11
|
33
|
36
|
2300
|
4600
|
164.0
|
169.0
|
|
1/2
|
12.70
|
39
|
43
|
3000
|
6000
|
210.0
|
216.0
|
|
5/8
|
15.80
|
45
|
53
|
4700
|
9400
|
334.0
|
344.0
|
|
3/4
|
19.00
|
55
|
63
|
6800
|
13600
|
485.0
|
499.0
|
|
7/8
|
22.20
|
64
|
74
|
9250
|
18500
|
656.0
|
675.0
|
|
1
|
25.40
|
73
|
84
|
12150
|
24300
|
870.0
|
896.0
|
