DHP Type Electric Hoist

PRODUCTS

HOME >PRODUCT > DHP Type Electric Hoist

Description

DHP Type Electric Hoist Introduction:
DHP electric endless chain motor lifting hoist is the new product of our company. It is either easy to carry or improve the disadvantage of manual operation and low lifting

DHP Type Electric Hoist Parameters：

Model	DHP1	DHP2	DHP3	DHP5	DHP10
Rated load T	1T	2T	3T	5T	10T
Testing load T	1.25T	2.5T	3.75T	6.25T	12.5T
Lifting speed m/min	2.5m/min	2.5m/min	2m/min	2m/min	1m/min
Loop track minimum Radius mm	300	380	470	600	730
Standard lift m	3 M
Power	0.5KW	0.8KW	1.1KW	1.5KW	0.8KW
Frequency HZ	380V 50HZ
Weight	42Kg	50Kg	55Kg	62Kg	120Kg
