MATERIAL：（U1：CM370；U2：CM490；U3：CM690）
|
D(φ)
DIAMETER |
CHAIN LINK SIZE
|
AM1
U1 STUD LINK CHAIN |
AM2
U2 STUD LINK CHAIN |
AM3
U3 STUD LINK CHAIN |
APPROX.
WEIGHT |
|||||
|
L
OUTSIDE LENGTH |
B
OUTSIDE WIDTH |
PROOF
LOAD |
BREAKING
LOAD |
PROOF LOAD |
BREAKING
LOAD |
PROOF
LOAD |
BREAKING
LOAD |
27.5M
|
||
|
INCH
|
MM
|
MM
|
MM
|
KN
|
KN
|
KN
|
KN
|
KN
|
KN
|
KG
|
|
1/2
|
12.5
|
75
|
45
|
46
|
66
|
66
|
92
|
92
|
132
|
98.00
|
|
9/16
|
14
|
84
|
50.4
|
58
|
82
|
82
|
116
|
116
|
165
|
119.00
|
|
5/8
|
16
|
96
|
57.6
|
76
|
107
|
107
|
150
|
150
|
216
|
156.00
|
|
11/16
|
17.5
|
105
|
63
|
89
|
127
|
127
|
179
|
179
|
256
|
186.00
|
|
3/4
|
19
|
114
|
68.4
|
105
|
150
|
150
|
211
|
211
|
301
|
230.00
|
|
13/16
|
20.5
|
123
|
73.8
|
123
|
175
|
175
|
244
|
244
|
349
|
260.00
|
|
7/8
|
22
|
132
|
79.2
|
140
|
200
|
200
|
280
|
280
|
401
|
300.00
|
|
15/16
|
24
|
144
|
86.4
|
167
|
237
|
237
|
332
|
332
|
476
|
370.00
|
|
1-1/16
|
26
|
156
|
93.6
|
194
|
278
|
278
|
389
|
389
|
556
|
431.00
|
|
1-1/8
|
28
|
168
|
100.8
|
225
|
321
|
321
|
449
|
449
|
642
|
496.00
|
|
1-3/16
|
30
|
180
|
108
|
257
|
368
|
368
|
514
|
514
|
735
|
564.00
|
|
1-1/4
|
32
|
192
|
115.2
|
291
|
417
|
417
|
583
|
583
|
833
|
635.00
|
|
1-5/16
|
34
|
204
|
122.4
|
328
|
468
|
468
|
655
|
655
|
937
|
712.00
|
|
1-7/16
|
36
|
216
|
129.6
|
366
|
523
|
523
|
732
|
732
|
1050
|
800.00
|
|
1-1/2
|
38
|
228
|
136.8
|
406
|
581
|
581
|
812
|
812
|
1160
|
887.00
|
|
1-9/16
|
40
|
240
|
144
|
448
|
640
|
640
|
896
|
896
|
1280
|
1032.00
|
|
1-5/8
|
42
|
252
|
151.2
|
492
|
703
|
703
|
981
|
981
|
1400
|
1084.00
|
|
1-3/4
|
44
|
264
|
158.4
|
538
|
769
|
769
|
1080
|
1080
|
1540
|
1197.00
|
|
1-13/16
|
46
|
276
|
165.6
|
585
|
837
|
837
|
1170
|
1170
|
1680
|
1310.00
|
|
1-7/8
|
48
|
288
|
172.8
|
635
|
908
|
908
|
1270
|
1270
|
1810
|
1438.00
|
|
2
|
50
|
300
|
180
|
686
|
981
|
981
|
1370
|
1370
|
1960
|
1546.00
|
|
2-1/16
|
52
|
312
|
187.2
|
739
|
1060
|
1060
|
1480
|
1480
|
2110
|
1661.00
|
|
2-1/8
|
54
|
324
|
194.4
|
794
|
1140
|
1140
|
1590
|
1590
|
2270
|
1791.00
|
|
2-3/16
|
56
|
336
|
201.6
|
851
|
1220
|
1220
|
1710
|
1710
|
2430
|
1926.00
|
|
2-5/16
|
58
|
348
|
208.8
|
909
|
1290
|
1290
|
1810
|
1810
|
2600
|
2086.00
|
|
2-3/8
|
60
|
360
|
216
|
969
|
1380
|
1380
|
1940
|
1940
|
2770
|
2249.00
|
|
2-7/16
|
62
|
372
|
223.2
|
1030
|
1470
|
1470
|
2060
|
2060
|
2940
|
2361.00
|
|
2-1/2
|
64
|
384
|
230.4
|
1100
|
1560
|
1560
|
2190
|
2190
|
3130
|
2516.00
|
|
2-9/16
|
66
|
396
|
237.6
|
1160
|
1660
|
1660
|
2310
|
2310
|
3300
|
2676.00
|
|
2-11/16
|
68
|
408
|
244.8
|
1230
|
1750
|
1750
|
2450
|
2450
|
3500
|
2885.00
|
|
2-3/4
|
70
|
420
|
252
|
1290
|
1840
|
1840
|
2580
|
2580
|
3690
|
3010.00
|
